What is Highcharts?

Highcharts is a robust, open-source JavaScript library used for creating interactive and visually appealing charts and graphs on websites and web applications. It allows developers to easily integrate a variety of chart types, including line charts, bar charts, pie charts, scatter plots, and more. Highcharts is particularly known for its interactivity, such as zooming, panning, tooltips, and dynamic data updates, which significantly enhance user experience.

Highcharts simplifies the process of turning complex data into understandable, interactive visualizations. It works seamlessly with modern web technologies, including HTML, CSS, and JavaScript, and is compatible with numerous back-end technologies like Node.js, Python, PHP, and Java. The library is cross-platform and supports all major browsers, including Chrome, Firefox, Safari, and Edge.

Highcharts is available in both a free version for non-commercial use and a paid version for commercial use, with additional features and support.

Core Features of Highcharts:

1. Wide Range of Chart Types: Highcharts supports a wide range of chart types, such as line charts, bar charts, pie charts, area charts, bubble charts, and more. It also supports advanced charts like gauges, heatmaps, and polar charts.
2. Interactive Features: Highcharts allows users to interact with charts by zooming, panning, hovering over points to view detailed information, and dynamically updating data.
3. Responsive Design: Charts are designed to be responsive, meaning they automatically adjust to the screen size or container they are placed in, ensuring compatibility with mobile and tablet devices.
4. Exporting Capabilities: Highcharts provides built-in functionality to export charts to different formats such as PNG, JPEG, PDF, or SVG.
5. Data-Driven: Highcharts supports both static and dynamic data, making it easy to visualize real-time data with minimal effort.
6. Plugins and Extensions: Highcharts supports a range of plugins, including Highcharts Maps for geographical data, Highcharts Stock for financial data, and Highcharts Gantt for project management timelines.

---

What are the Major Use Cases of Highcharts?

Highcharts is widely used in a variety of fields, from data visualization in business intelligence platforms to real-time analytics in web applications. Below are the major use cases for Highcharts:

1. Business Intelligence (BI) and Analytics

One of the most common use cases of Highcharts is to display business intelligence metrics and analytics in dashboards. Organizations use Highcharts to present real-time data insights, trends, and performance indicators in an interactive and engaging way. With its diverse chart types and customization options, Highcharts is perfect for visualizing KPIs, sales metrics, user engagement data, and much more.

Example:
A business intelligence platform might use Highcharts to display a real-time dashboard showing sales performance by region, customer demographics, and growth trends.

2. Financial and Stock Market Visualization

Highcharts is widely used in financial services to create real-time financial charts, stock market performance graphs, and other financial data visualizations. It supports time-series charts, candlestick charts, and other financial chart types to display historical market data, price trends, and trading volumes. The real-time data updates, interactivity, and zooming features make it ideal for traders and investors.

Example:
A financial application might use Highcharts to display stock market prices in real time, allowing users to view historical performance and analyze price trends through line and candlestick charts.

3. Scientific Data Visualization

Highcharts is widely used in scientific and academic research for visualizing experimental results, population studies, geographical data, and more. The ability to display complex data in various chart forms, such as scatter plots, bubble charts, and heatmaps, makes it an excellent tool for scientific research.

Example:
A scientific study on climate change might use Highcharts to visualize temperature trends over time, comparing different regions with interactive line charts.

4. Data Reporting and Real-Time Dashboards

Highcharts is frequently used in web applications to generate real-time data reports and dashboards. These dashboards display critical data in an interactive format, allowing users to explore the data dynamically. Users can zoom in, filter, and adjust the range of displayed data to get a better understanding of performance metrics, trends, and other key statistics.

Example:
A web application used by a marketing team might include a dashboard with Highcharts charts showing website traffic, user engagement, and conversion rates.

5. Geospatial Data Visualization (Highcharts Maps)

Highcharts includes Highcharts Maps, an extension that enables the creation of geographic data visualizations. This is particularly useful for visualizing data like population density, regional statistics, or election results. Highcharts Maps uses geographical shapes to represent data in an intuitive, color-coded way.

Example:
A political campaign might use Highcharts Maps to display election results across various regions or districts, with each region color-coded according to the winning candidate.

6. Project Management with Gantt Charts (Highcharts Gantt)

Highcharts provides a specialized plugin called Highcharts Gantt, which is used to display project timelines, schedules, and task progress. This is helpful for project managers and teams to track milestones, deadlines, and dependencies in a visual and interactive way.

Example:
A software development team might use Highcharts Gantt to visualize a project’s timeline, including tasks, milestones, and resource allocation.

---

How Highcharts Works Along with Architecture?

Highcharts is based on a JavaScript framework that leverages HTML5, SVG (Scalable Vector Graphics), and CSS to render charts on the web. Its architecture allows for both static and dynamic chart rendering, offering flexibility in how data is visualized.

Core Components of Highcharts Architecture:

• Chart Object
  The chart object is the central component in Highcharts. It is created using the Highcharts.chart() function and stores all the properties of the chart, including the type, title, axes, series, and other configurations. The chart object is responsible for rendering the chart to the DOM.

Highcharts.chart('container', {
    chart: {
        type: 'line'
    },
    title: {
        text: 'My First Chart'
    },
    series: [{
        name: 'Data Series',
        data: [1, 2, 3, 4, 5]
    }]
});

• Axes
  Highcharts charts are equipped with axes (X-axis, Y-axis, and sometimes multiple axes) to plot the data. These axes help in scaling the data to fit within the chart area and provide a reference for the data points. Highcharts allows for customization of axes, such as setting axis types, labels, titles, gridlines, and more.

xAxis: {
    categories: ['Jan', 'Feb', 'Mar', 'Apr']
},
yAxis: {
    title: {
        text: 'Values'
    }
}

• Series
  A series represents a dataset that is displayed on the chart. A chart can have one or multiple series, depending on the data being visualized. Each series object includes the name, type of chart, data points, and various styling options.

series: [{
    name: 'Sales Data',
    data: [10, 20, 30, 40, 50]
}]

• Events and Interactivity
  Highcharts supports various events such as click, hover, and zoom, which allow users to interact with the chart. Event handling is a powerful feature in Highcharts, enabling users to trigger actions based on user interactions with chart elements.

plotOptions: {
    series: {
        point: {
            events: {
                click: function () {
                    alert('You clicked on a point!');
                }
            }
        }
    }
}

• Highcharts Rendering Engine
  Highcharts uses SVG for rendering charts by default, which ensures high-quality, scalable graphics. It also provides options to render charts using HTML5 Canvas or VML (Vector Markup Language) for compatibility with older browsers like Internet Explorer.
  • SVG: A flexible vector graphics format that allows charts to be scaled without losing quality.
  • Canvas: An HTML5 element used for rendering graphics, suitable for high-performance chart rendering.
  • VML: A Microsoft XML-based graphics format used for rendering in Internet Explorer 8 and earlier.
• Themes and Styling
  Highcharts provides extensive customization options for styling charts, such as changing colors, fonts, borders, and chart elements. You can apply themes to entire charts, or even to individual components like axes or series.

chart: {
    backgroundColor: '#f5f5f5'
},
title: {
    style: {
        color: '#333',
        fontSize: '20px'
    }
}

---

Basic Workflow of Highcharts

The typical workflow for creating a chart using Highcharts involves the following steps:

• Include Highcharts Library:
  Include the Highcharts library via a <script> tag or use a CDN link in your HTML file.

<script src="https://code.highcharts.com/highcharts.js"></script>

• Create a Container:
  Set up an HTML container (e.g., a <div>) where the chart will be rendered.

<div id="container"></div>

• Configure Chart Settings:
  Create a configuration object in JavaScript, specifying properties like chart type, title, data series, axes, and styling.
• Render the Chart:
  Use the Highcharts.chart() function to render the chart inside the container.
• Interactivity and Customization:
  Add interactive features such as events, tooltips, and zooming/panning options.
• Export or Share the Chart:
  Highcharts allows exporting charts to formats like PNG, JPEG, and PDF, and sharing charts via URL or embedding them on websites.

---

Step-by-Step Getting Started Guide for Highcharts

Step 1: Install Highcharts

To use Highcharts, you can either download the library or include it through a CDN in your HTML. Here’s how you can use the CDN:

<script src="https://code.highcharts.com/highcharts.js"></script>

Step 2: Create a Container for the Chart

Create a <div> element in your HTML where the chart will be displayed. Make sure to give it a unique id.

<div id="container" style="width:100%; height:400px;"></div>

Step 3: Initialize the Chart

In your JavaScript, use the Highcharts.chart() function to initialize the chart. Below is an example of a simple line chart:

Highcharts.chart('container', {
    chart: { type: 'line' },
    title: { text: 'My First Highcharts Chart' },
    series: [{
        name: 'Sales',
        data: [1, 2, 3, 4, 5]
    }]
});

Step 4: Customize the Chart

You can customize various elements of the chart such as the axes, tooltips, series, and more. Here’s how to add a subtitle and change the axis labels:

Highcharts.chart('container', {
    chart: { type: 'line' },
    title: { text: 'My First Highcharts Chart' },
    subtitle: { text: 'Data for 2021' },
    xAxis: { categories: ['Jan', 'Feb', 'Mar', 'Apr', 'May'] },
    series: [{
        name: 'Sales',
        data: [1, 2, 3, 4, 5]
    }]
});

Step 5: Add Interactive Features

Highcharts allows you to add interactivity, such as click events on data points. You can trigger actions when users click on a point:

Highcharts.chart('container', {
    chart: { type: 'line' },
    title: { text: 'Interactive Chart' },
    series: [{
        name: 'Sales',
        data: [1, 2, 3, 4, 5]
    }],
    plotOptions: {
        series: {
            point: {
                events: {
                    click: function () {
                        alert('You clicked on ' + this.category);
                    }
                }
            }
        }
    }
});

Step 6: Export and Share

Highcharts allows users to export charts as images or PDF files. You can enable this functionality with the following option:

Highcharts.chart('container', {
    chart: { type: 'line' },
    title: { text: 'Exportable Chart' },
    exporting: { enabled: true },
    series: [{
        name: 'Sales',
        data: [1, 2, 3, 4, 5]
    }]
});
